- Preview
- Code
{
"connect_token": "cot_6587fa4362341be5b524de3b",
"route": "plan_structure",
"live_mode": false,
"actions": [
"BACK"
],
"data": {
"provider": {
"id": "prv_65de304bba73636872c17c11",
"display_name": "E-ON",
"logo_url": "https://s.flatpeak.com/73636872c17c11.png"
},
"options": [
"FIXED",
"TIME_OF_DAY",
"MARKET",
"ADVANCED_TARIFF_INPUT"
]
}
}
Actions
Following actions are supported when responding to Connect on this route:| Action | Result |
|---|---|
FIXED | Customer will be requested to input their fixed (flat) tariff rate. |
TIME_OF_DAY | Customer will be requested to input their variable tariff rate. |
MARKET | Connect will automatically detect the customer’s market rate using their postal address. It will then provide the customer with an option to indicate what fees and/or surcharges they are paying to their provider on top of that rate. |
BACK | Returns previous page. |
CLOSE | Returns callback_url you specified when creating the Connect token. |
Errors
When you POST your response to Connect, the following validation errors may be returned:| Error Code | Error Description |
|---|---|
option_invalid | The options array can only contain one item. |
option_not_supported | Unsupported option parameter XX. |
data_json_invalid | Data does not conform to the JSON schema. |
